Get Started

Setup

Install github.observatory by using:

install.packages("remotes")
remotes::install_github("harell/github.observatory")

Set AWS credentials in order to get access to the curated data

Sys.setenv(
    AWS_ACCESS_KEY_ID = "<your-access-key-id>",
    AWS_SECRET_ACCESS_KEY= "<your-secret>",
    AWS_REGION = "ap-southeast-2"
)

github.observatory gives easy access to the project database through a Repository object named Ecosystem. To access the database, instantiate a Ecosystem object.

ecos <- Ecosystem$new()

Instantiate a Recommendation Agent. See Agent Functions for details.

agent <- Agent$new(ecos)

Terminology

Entities

Package: An R package that is available on CRAN. For example, dplyr.
Repo: A Github reposetory that corresponds to a Package. For example, tidyverse/dplyr.
User: A Github user. There are two ways to identify a User:
- user_login this is a mutable name of the Github account chosen by the User. It is apparent in the Github URL. For example, https://github.com/harell corresponds to user_login = harell; and
- user_id this is an immutable number assign by Github when the User creates an account. user_id is not readily available and has to be deduced from an API call. For example, user_id = 7226303, corresponds to user_login = harell , and the respective API call is https://api.github.com/user/7226303.

Tip: Among the two options to identify a User, user_id is preferable as it stays the same throughout the life of GitHub. See the Mapping Entities section for how to locate user_id with user_login.

Roles

Stargazer: A User that give a ★ (star) to a Repo.

Ecosystem Overview

The Ecosystem gives access to SPECTATOR, FOLLOWING, DEPENDENCY, PACKAGE, REPO and USER tables.

Tip: See the tables content at the Appendix

Mapping Entities

`user_id` to `user_login`

Finding a user_id with user_login

user_login <- "harell"
(
    user_id <- ecos$read_USER()
    |> dplyr::filter(login %in% user_login)
    |> dplyr::pull(id)
)
#> [1] 7226303

`package` (CRAN package name) to `repo_id`

cran_package <- "dplyr"
(
    repo_id <- ecos$read_REPO()
    |> dplyr::filter(package %in% cran_package)
    |> dplyr::pull(id)
)
#> [1] 6427813

Agent Functions

The Recommendation Agent has five functions:

recommend_repos_to_user Given a user_id suggests n repos the user might like;
recommend_users_to_user Given a user_id suggests n users the user might like;
query_repos_graph Given a repo_id and a method, find all linked packages in degrees degrees of separation;
query_users_graph Given a user_id and a method, find all linked users in degrees degrees of separation; and
query_package_stats Given a CRAN package name, and a particular statistic (a function of the data sample), return the value of the requested attribute.

Recommend 5 Repos to a user (see Agent help file for supported methods)

suggested_repos <- agent$recommend_repos_to_user(user_id, n = 5, method = "random")
print(suggested_repos)
#> # A tibble: 5 × 2
#>    rank   repo_id
#>   <int>     <int>
#> 1     1 171659421
#> 2     2  85225301
#> 3     3  29305085
#> 4     4 190079713
#> 5     5 107019949

Add details to the recommended Repos

(
    suggested_repos
    |> dplyr::left_join(ecos$read_REPO(), by = c("repo_id" = "id"))
)
#> # A tibble: 5 × 16
#>    rank  repo_id package full_…¹ owner…² owner…³ html_…⁴ starg…⁵ watch…⁶ forks…⁷
#>   <int>    <dbl> <chr>   <chr>   <chr>     <dbl> <chr>     <dbl>   <dbl>   <dbl>
#> 1     1   1.72e8 correl… easyst… Organi…  4.71e7 https:…     324      14      42
#> 2     2   8.52e7 iheatm… ropens… Organi…  1.20e6 https:…     252      21      33
#> 3     3   2.93e7 openair davidc… User     1.24e6 https:…     224      38      95
#> 4     4   1.90e8 ymlthis r-lib/… Organi…  2.26e7 https:…     153       8       8
#> 5     5   1.07e8 linl    eddelb… User     6.73e5 https:…     105       7      14
#> # … with 6 more variables: language <chr>, homepage <chr>, created_at <date>,
#> #   updated_at <date>, queried_at <date>, processed_at <date>, and abbreviated
#> #   variable names ¹full_name, ²owner_type, ³owner_id, ⁴html_url,
#> #   ⁵stargazers_count, ⁶watchers_count, ⁷forks_count

Recommend 5 Users to a user (see Agent help file for supported methods)

suggested_users <- agent$recommend_users_to_user(user_id, n = 5, method = "random")
print(suggested_users)
#> # A tibble: 5 × 2
#>    rank  user_id
#>   <int>    <int>
#> 1     1  4011804
#> 2     2 10975252
#> 3     3   629060
#> 4     4 21288394
#> 5     5 21098186

Add details to the recommended Users

(
    suggested_users
    |> dplyr::left_join(ecos$read_USER(), by = c("user_id" = "id"))
)
#> # A tibble: 5 × 18
#>    rank  user_id login     avata…¹ html_…² name  publi…³ follo…⁴ follo…⁵ r_fol…⁶
#>   <int>    <dbl> <chr>     <chr>   <chr>   <chr>   <dbl>   <dbl>   <dbl>   <dbl>
#> 1     1  4011804 pzhaonet  https:… https:… Peng…     166     264       6     175
#> 2     2 10975252 andrewli… https:… https:… Andr…     103     190      66      73
#> 3     3   629060 software… https:… https:… Doug…      38     145      10      45
#> 4     4 21288394 abigger87 https:… https:… NA        159     388     546      45
#> 5     5 21098186 greed2411 https:… https:… Jaiv…      58     142     158      36
#> # … with 8 more variables: r_following <dbl>, r_contributor_count <dbl>,
#> #   r_watcher_count <dbl>, r_stargazer_count <dbl>, created_at <date>,
#> #   updated_at <date>, queried_at <date>, processed_at <date>, and abbreviated
#> #   variable names ¹avatar_url, ²html_url, ³public_repos, ⁴followers,
#> #   ⁵following, ⁶r_followers

Query Repos Graph

To query the repo graph, you need to supply three input arguments:

repo_id: See Mapping Entities for how to map a package name to repo_id);
degree: How many neighbourhood to retrieve?
method: Either depends or reverse depends
- depends returns the package dependencies (as appears in its DESCRIPTION file);
- reverse depends returns packages that are dependent on repo_id.

Query package dependencies

Find the dependencies of a package

repo_dep <- agent$query_repos_graph(repo_id, degrees = 1, method = "depends")
print(repo_dep)
#> # A tibble: 11 × 3
#>    degree    from        to
#>     <dbl>   <dbl>     <dbl>
#>  1      0 6427813   6427813
#>  2      1 6427813 137095400
#>  3      1 6427813  77250656
#>  4      1 6427813 163315535
#>  5      1 6427813  15564525
#>  6      1 6427813  91374446
#>  7      1 6427813  19521307
#>  8      1 6427813  73098312
#>  9      1 6427813  45148983
#> 10      1 6427813  92205415
#> 11      1 6427813  67548397

Add details to the Package dependencies

(
    repo_dep
    |> dplyr::left_join(ecos$read_REPO(), by = c("to" = "id"))
)
#> # A tibble: 11 × 17
#>    degree    from     to package full_…¹ owner…² owner…³ html_…⁴ starg…⁵ watch…⁶
#>     <dbl>   <dbl>  <dbl> <chr>   <chr>   <chr>     <dbl> <chr>     <dbl>   <dbl>
#>  1      0 6427813 6.43e6 dplyr   tidyve… Organi…  2.20e7 https:…    4088     253
#>  2      1 6427813 1.37e8 generi… r-lib/… Organi…  2.26e7 https:…      57       4
#>  3      1 6427813 7.73e7 glue    tidyve… Organi…  2.20e7 https:…     606      18
#>  4      1 6427813 1.63e8 lifecy… r-lib/… Organi…  2.26e7 https:…      75       6
#>  5      1 6427813 1.56e7 magrit… tidyve… Organi…  2.20e7 https:…     894      56
#>  6      1 6427813 9.14e7 pillar  r-lib/… Organi…  2.26e7 https:…     144      10
#>  7      1 6427813 1.95e7 R6      r-lib/… Organi…  2.26e7 https:…     353      21
#>  8      1 6427813 7.31e7 rlang   r-lib/… Organi…  2.26e7 https:…     383      21
#>  9      1 6427813 4.51e7 tibble  tidyve… Organi…  2.20e7 https:…     530      33
#> 10      1 6427813 9.22e7 tidyse… r-lib/… Organi…  2.26e7 https:…     106       8
#> 11      1 6427813 6.75e7 vctrs   r-lib/… Organi…  2.26e7 https:…     233      10
#> # … with 7 more variables: forks_count <dbl>, language <chr>, homepage <chr>,
#> #   created_at <date>, updated_at <date>, queried_at <date>,
#> #   processed_at <date>, and abbreviated variable names ¹full_name,
#> #   ²owner_type, ³owner_id, ⁴html_url, ⁵stargazers_count, ⁶watchers_count

Query package reverse dependencies

Find the reverse dependencies of a package

repo_rev_dep <- agent$query_repos_graph(repo_id, degrees = 1, method = "reverse")
print(repo_rev_dep)
#> # A tibble: 2,601 × 3
#>    degree      from      to
#>     <dbl>     <dbl>   <dbl>
#>  1      0   6427813 6427813
#>  2      1 221466628 6427813
#>  3      1  78038172 6427813
#>  4      1 340095903 6427813
#>  5      1 201294705 6427813
#>  6      1  80061030 6427813
#>  7      1 447452022 6427813
#>  8      1  39196192 6427813
#>  9      1 334079562 6427813
#> 10      1 244196790 6427813
#> # … with 2,591 more rows

Add details to the Package dependencies

(
    repo_rev_dep
    |> dplyr::left_join(ecos$read_REPO(), by = c("from" = "id"))
)
#> # A tibble: 2,601 × 17
#>    degree    from     to package full_…¹ owner…² owner…³ html_…⁴ starg…⁵ watch…⁶
#>     <dbl>   <dbl>  <dbl> <chr>   <chr>   <chr>     <dbl> <chr>     <dbl>   <dbl>
#>  1      0  6.43e6 6.43e6 dplyr   tidyve… Organi…  2.20e7 https:…    4088     253
#>  2      1  2.21e8 6.43e6 AATtoo… spirit… User     3.53e7 https:…       0       1
#>  3      1  7.80e7 6.43e6 abjuti… cran/a… Organi…  6.90e6 https:…       1       3
#>  4      1  3.40e8 6.43e6 academ… cjbarr… User     2.96e7 https:…     211       6
#>  5      1  2.01e8 6.43e6 accept  cran/a… Organi…  6.90e6 https:…       0       2
#>  6      1  8.01e7 6.43e6 accucor xiaoya… User     1.43e7 https:…      11       7
#>  7      1  4.47e8 6.43e6 ACDC    cran/a… Organi…  6.90e6 https:…       0       2
#>  8      1  3.92e7 6.43e6 ACDm    cran/a… Organi…  6.90e6 https:…       1       1
#>  9      1  3.34e8 6.43e6 acrona… cran/a… Organi…  6.90e6 https:…       0       3
#> 10      1  2.44e8 6.43e6 ActCR   junrui… User     1.41e7 https:…       1       1
#> # … with 2,591 more rows, 7 more variables: forks_count <dbl>, language <chr>,
#> #   homepage <chr>, created_at <date>, updated_at <date>, queried_at <date>,
#> #   processed_at <date>, and abbreviated variable names ¹full_name,
#> #   ²owner_type, ³owner_id, ⁴html_url, ⁵stargazers_count, ⁶watchers_count

Query Users Graph

To query the repo graph, you need to supply three input arguments:

repo_id: See Mapping Entities for how to map a package name to repo_id);
degree: How many neighbourhood to retrieve?
method: Either followers or following
- followers What users are following user_id?; or
- following What users is user_id following?

Query user followers

Find who is following user_id

user_followers <- agent$query_users_graph(user_id, degrees = 1, method = "followers")
print(user_followers)
#> # A tibble: 6 × 3
#>   degree     from      to
#>    <dbl>    <dbl>   <dbl>
#> 1      0  7226303 7226303
#> 2      1 52979198 7226303
#> 3      1 31113760 7226303
#> 4      1 10200210 7226303
#> 5      1  3811321 7226303
#> 6      1  6518676 7226303

Add details to user_id followers

(
    user_followers
    |> dplyr::left_join(ecos$read_USER(), by = c("from" = "id"))
)
#> # A tibble: 6 × 19
#>   degree     from      to login    avata…¹ html_…² name  publi…³ follo…⁴ follo…⁵
#>    <dbl>    <dbl>   <dbl> <chr>    <chr>   <chr>   <chr>   <dbl>   <dbl>   <dbl>
#> 1      0  7226303 7226303 harell   https:… https:… NA         13       6      64
#> 2      1 52979198 7226303 angelor… https:… https:… Ange…       6       9      18
#> 3      1 31113760 7226303 rfdorne… https:… https:… Rodr…       9      37     183
#> 4      1 10200210 7226303 asdspal  https:… https:… NA         22       5       2
#> 5      1  3811321 7226303 maskegg… https:… https:… Am        344      82    3851
#> 6      1  6518676 7226303 bcgalvin https:… https:… Brya…      19      41     367
#> # … with 9 more variables: r_followers <dbl>, r_following <dbl>,
#> #   r_contributor_count <dbl>, r_watcher_count <dbl>, r_stargazer_count <dbl>,
#> #   created_at <date>, updated_at <date>, queried_at <date>,
#> #   processed_at <date>, and abbreviated variable names ¹avatar_url, ²html_url,
#> #   ³public_repos, ⁴followers, ⁵following

Query user following

Find who is user_id following

user_following <- agent$query_users_graph(user_id, degrees = 1, method = "following")
print(user_following)
#> # A tibble: 56 × 3
#>    degree    from      to
#>     <dbl>   <dbl>   <dbl>
#>  1      0 7226303 7226303
#>  2      1 7226303    4196
#>  3      1 7226303   86978
#>  4      1 7226303   93231
#>  5      1 7226303  104391
#>  6      1 7226303  129551
#>  7      1 7226303  205275
#>  8      1 7226303  216319
#>  9      1 7226303  227097
#> 10      1 7226303  470418
#> # … with 46 more rows

Add details to those who user_id is following

(
    user_following
    |> dplyr::left_join(ecos$read_USER(), by = c("to" = "id"))
)
#> # A tibble: 56 × 19
#>    degree    from      to login    avata…¹ html_…² name  publi…³ follo…⁴ follo…⁵
#>     <dbl>   <dbl>   <dbl> <chr>    <chr>   <chr>   <chr>   <dbl>   <dbl>   <dbl>
#>  1      0 7226303 7226303 harell   https:… https:… NA         13       6      64
#>  2      1 7226303    4196 hadley   https:… https:… Hadl…     176   22465       0
#>  3      1 7226303   86978 wch      https:… https:… Wins…     125    1326       0
#>  4      1 7226303   93231 schloer… https:… https:… Barr…     186     221       6
#>  5      1 7226303  104391 jjallai… https:… https:… J j …     138    1498       0
#>  6      1 7226303  129551 jcheng5  https:… https:… Joe …     159    1780      12
#>  7      1 7226303  205275 jimhest… https:… https:… Jim …     454    1481       8
#>  8      1 7226303  216319 jeroen   https:… https:… Jero…     303    1550     356
#>  9      1 7226303  227097 kohske   https:… https:… Kohs…      43      61       1
#> 10      1 7226303  470418 jmcphers https:… https:… Jona…      39     389      11
#> # … with 46 more rows, 9 more variables: r_followers <dbl>, r_following <dbl>,
#> #   r_contributor_count <dbl>, r_watcher_count <dbl>, r_stargazer_count <dbl>,
#> #   created_at <date>, updated_at <date>, queried_at <date>,
#> #   processed_at <date>, and abbreviated variable names ¹avatar_url, ²html_url,
#> #   ³public_repos, ⁴followers, ⁵following

Query Package Stats

Monthly Downloads

Find how many times dplyr was downloaded every month

package_downloads <- agent$query_package_stats("dplyr", statistic = "monthly downloads")
package_downloads |> tail(n = 12) |> print()
#> # A tibble: 12 × 3
#>    date       package downloads
#>    <date>     <chr>       <dbl>
#>  1 2021-08-01 dplyr     1483396
#>  2 2021-09-01 dplyr     1630109
#>  3 2021-10-01 dplyr     1821037
#>  4 2021-11-01 dplyr     1680463
#>  5 2021-12-01 dplyr     1438504
#>  6 2022-01-01 dplyr     1411385
#>  7 2022-02-01 dplyr     1552862
#>  8 2022-03-01 dplyr     1764950
#>  9 2022-04-01 dplyr     1791634
#> 10 2022-05-01 dplyr     2132210
#> 11 2022-06-01 dplyr     1855881
#> 12 2022-07-01 dplyr     1659440

Plot the monthly downloads

plot(
    package_downloads$date, package_downloads$downloads,
    main = "Monthly downloads of `dplyr` from RStudio CRAN mirror",
    type = "b", xlab = "Date", ylab = "Monthly Downloads"
)

Appendix

Ecosystem Tables Overview

#>
#>
#> ## SPECTATOR
#> Rows: 544,970
#> Columns: 3
#> $ repo_id   <dbl> 465098622, 465098622, 465098622, 465098622, 465098622, 38745…
#> $ user_id   <dbl> 6008722, 6676074, 5859205, 6676074, 10773123, 5303237, 53032…
#> $ user_role <chr> "contributor", "contributor", "watcher", "watcher", "watcher…
#>
#>
#> ## FOLLOWING
#> Rows: 855,628
#> Columns: 2
#> $ from <dbl> 18198064, 18198064, 18198064, 18198064, 30104471, 502944, 502944,…
#> $ to   <dbl> 4196, 3680095, 24767886, 31291716, 2377676, 39391, 889502, 187262…
#>
#>
#> ## DEPENDENCY
#> Rows: 94,403
#> Columns: 2
#> $ from <chr> "A3", "A3", "aaSEA", "aaSEA", "aaSEA", "aaSEA", "aaSEA", "aaSEA",…
#> $ to   <chr> "pbapply", "xtable", "Bios2cor", "DT", "Hmisc", "magrittr", "netw…
#>
#>
#> ## PACKAGE
#> Rows: 18,481
#> Columns: 6
#> $ package      <chr> "A3", "AATtools", "ABACUS", "abbreviate", "abbyyR", "abc"…
#> $ full_name    <chr> "cran/A3", "spiritspeak/AATtools", "cran/ABACUS", "cran/a…
#> $ cran_version <chr> "1.0.0", "0.0.2", "1.0.0", "0.1", "0.5.5", "2.2.1", "1.0"…
#> $ cran_date    <date> 2015-08-16, 2022-08-12, 2019-09-12, 2021-12-12, 2019-06-…
#> $ title        <chr> "Accurate, Adaptable, and Accessible Error Metrics for Pr…
#> $ description  <chr> "Supplies tools for tabulating and analyzing the results …
#>
#>
#> ## REPO
#> Rows: 19,198
#> Columns: 15
#> $ id               <dbl> 465098622, 387458599, 525857196, 526663547, 526663485…
#> $ package          <chr> "rmzqc", "EloSteepness", "tLagInterim", "ambit", "Rob…
#> $ full_name        <chr> "ms-quality-hub/rmzqc", "gobbios/elosteepness", "cran…
#> $ owner_type       <chr> "Organization", "User", "Organization", "Organization…
#> $ owner_id         <dbl> 100718546, 5303237, 6899542, 6899542, 6899542, 267241…
#> $ html_url         <chr> "https://github.com/MS-Quality-hub/rmzqc", "https://g…
#> $ stargazers_count <dbl> 0, 0, 0, 0, 0, 2, 0, 0, 0, 18, 1, 0, 0, 0, 0, 0, 0, 0…
#> $ watchers_count   <dbl> 3, 1, 2, 2, 2, 1, 2, 2, 2, 1, 2, 2, 2, 2, 2, 2, 2, 2,…
#> $ forks_count      <dbl> 0, 0, 0, 0, 0, 0, 0, 0, 0, 15, 1, 0, 0, 0, 0, 0, 0, 0…
#> $ language         <chr> "R", "C++", "R", "R", "R", "R", "R", "R", "R", "JavaS…
#> $ homepage         <chr> NA, NA, NA, NA, NA, NA, NA, NA, NA, "https://g3viz.gi…
#> $ created_at       <date> 2022-03-02, 2021-07-19, 2022-08-17, 2022-08-19, 2022…
#> $ updated_at       <date> 2022-05-31, 2022-01-27, 2022-08-17, 2022-08-19, 2022…
#> $ queried_at       <date> 2022-08-21, 2022-08-21, 2022-08-21, 2022-08-21, 2022…
#> $ processed_at     <date> 2022-08-21, 2022-08-21, 2022-08-21, 2022-08-21, 2022…
#>
#>
#> ## USER
#> Rows: 142,007
#> Columns: 17
#> $ id                  <dbl> 94039735, 65328944, 18198064, 56229977, 109984500,…
#> $ login               <chr> "lingweiR", "bolrDK", "ksny", "VascoBranco", "YueP…
#> $ avatar_url          <chr> "https://avatars.githubusercontent.com/u/94039735?…
#> $ html_url            <chr> "https://github.com/lingweiR", "https://github.com…
#> $ name                <chr> "Lingwei", "Bo Larsen", "Kevin Snyder", "Vasco Bra…
#> $ public_repos        <dbl> 2, 0, 4, 2, 0, 71, 3, 2, 1, 3, 3, 0, 18, 37, 13, 0…
#> $ followers           <dbl> 0, 0, 7, 0, 0, 8, 1, 0, 0, 0, 0, 0, 6, 10, 1, 0, 1…
#> $ following           <dbl> 0, 0, 6, 0, 0, 9, 0, 0, 0, 1, 0, 0, 6, 12, 0, 0, 5…
#> $ r_followers         <dbl> 0, 0, 3, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 4, 0, 0, 1,…
#> $ r_following         <dbl> 0, 0, 4, 0, 0, 0, 0, 0, 0, 1, 0, 0, 0, 4, 0, 0, 4,…
#> $ r_contributor_count <dbl> 1, 1, 1, 1, 1, 1, 1, 1, 1, 0, 0, 1, 1, 0, 1, 0, 0,…
#> $ r_watcher_count     <dbl> 0, 0, 1, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0,…
#> $ r_stargazer_count   <dbl> 0, 0, 1, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 1, 0, 1, 1,…
#> $ created_at          <date> 2021-11-10, 2020-05-14, 2016-03-31, 2019-10-06, 2…
#> $ updated_at          <date> 2022-07-31, 2022-04-06, 2022-08-11, 2022-08-12, 2…
#> $ queried_at          <date> 2022-08-21, 2022-08-21, 2022-08-21, 2022-08-21, 2…
#> $ processed_at        <date> 2022-08-21, 2022-08-21, 2022-08-21, 2022-08-21, 2…
